Authorized Reseller

100 Series Dishwasher 24" White SHEM3AY52N

SKU/Model #: SHEM3AY52N Discontinued
100 Series Dishwasher 24" White
Authorized Reseller
SKU/Model #: SHEM3AY52N
100 Series Dishwasher 24" White
100 Series Dishwasher 24" White
100 Series Dishwasher 24" White
100 Series Dishwasher 24" White
100 Series Dishwasher 24" White
100 Series Dishwasher 24" White
100 Series Dishwasher 24" White
$466.00
List Price:
Instant Savings:
  • Protect your kitchen with the 24/7 Overflow Protection System®
  • A Standard Silverware Basket to store utensils on the bottom rack
  • A smarter clean with PrecisionWash®
  • Not just dry, but PureDry®
  • 50 dBA -- the quietest dishwasher brand in the U.S.*
  • Quality in every detail
BOSCH SHEM3AY52N 100 Series Dishwasher
Features and Specifications
General
Appliance Width (in) 23 9/16
Height 33 7/8
Installation Type Built-under
Number of Place Settings 14
List of Programs 1 Hour, Auto, Hand Wash, Normal, Pots & Pans, Rinse
Cycle Options Sanitation
Display Yes
Silence Level 50 dB(A) re 1 pW
3rd rack None
Interior Light No
Removable top No
Power Cord Length 67"
Connectivity
Home Connect™ No
Size and weight
Overall Appliance Dimensions (HxWxD) (in) 33 7/8'' x 23 9/16'' x 22 9/16''
Adjustable plinth both horizontal and vertical
Net Weight 73.000 lbs
Programmes
Status indicator Sanitized LED US, Time remaining indicator front
List of Programs 1 Hour, Auto, Hand Wash, Normal, Pots & Pans, Rinse
Program 1 Pots & Pans
Program 2 Auto
Program 3 Normal
Program 4 Hand Wash
Program 5 1 Hour
Program 6 Rinse
Programme duration, programme1 (min.) 110-130
Programme duration, programme2 (min.) 115-130
Programme duration, programme3 (min.) 130-135
Programme duration, programme4 (min.) 80-85
Programme duration, programme5 (min.) 60
Programme duration, programme6 (min.) 9
Reference program Regular US
Number of different wash temperatures 6
Temperature program 1 150-160 °F
Temperature program 2 125-130 °F
Temperature program 3 122-131 °F
Temperature program 4 113-122 °F
Temperature program 5 127 °F
Safety
ChildLock Button suspension
Consumption values
Glass protection No
Water consumption program 1 5.7-7.3 gal
Water consumption program 2 3.8-6.5 gal
Water consumption program 3 3-5.7 gal
Water consumption program 4 3-4.4 gal
Water consumption program 5 4.5 gal
Water consumption program 6 1.1 gal
Total Annual Water Consumption 688 gal
Maximum temperature for water intake (°C) 50 °C
Connection
Watts 1,440 W
Power Cord Length 67"
Fuse protection 12 A
Plug type Nema5-15P
Construction type
Color / Material housing Lacquered
Color / Control Panel White
Construction Type Built-in
Drying System Inherent heat
Height 33 7/8
Concealed heating element Yes
Installation Type Built-under
Tub material Plastic
Water Softener No
Appliance Width (in) 23 9/16
