Warranty |
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com |
SHIPPING WEIGHT (kg) |
37.30 |
NET WEIGHT (kg) |
30.70 |
CARTON LENGHT (mm) |
866.00 |
CARTON HEIGHT (mm) |
350.00 |
CARTON DEPTH (mm) |
678.00 |
VOLUMEN (M3) |
0.20 |
SHIPPING WEIGHT |
82.23 |
NET WEIGHT |
67.68 |
CARTON LENGHT |
34.09 |
CARTON HEIGHT |
13.78 |
CARTON DEPTH |
26.69 |
COUNTRY OF MANUFACTURE |
MX |
Finish |
Black Ceramic Glass |
Color |
Deep-black |
FEATURES |
Timer,Easy to mantain,Stop and go,Delay switch off,_x001E_Temperature manager,Bridge zones,Total integration,Airmatic,CFM reduction system,Pot self-detection,Touch controls , Child lock , Long life filter ++ |
WIDTH (IN) |
30" |
WIDTH (CM) |
76.00 |
AIRFLOW (M3/H) |
1020.00 |
CFM (MAX) |
600.00 |
db (min) |
NA |
db (max) |
36.40 |
SONES |
1.8 - 6.8 |
GREASE FILTER TYPE |
YES |
DISHWASHERSAFE FILTER |
YES |
FILTER MATERIAL |
Aluminum |
BLOWER TYPE |
Interior Unit |
EXHAUST SIZE |
Rectangular 10 x 3 1/4" or round 6" (Included) |
CONTROL TYPE |
Electronic Glass Touch & Slide w/ Red Illumination |
SPEED CONTROL |
YES |
NUMBER OF SPEEDS |
4.00 |
REMOTE CONTROL |
NO |
POWER SOURCE |
Hardwired |
CFM REDUCTION |
YES |
HEATING LEVEL |
9 levels + Boost |
COOKING ZONE |
4.00 |
Burner Style |
Induction |
Cooktop Type |
Downdraft Cooktop |
Fuel Type |
Induction |
Element Type |
Induction |
Ignition Type |
Automatic Electronic |
Induction |
Yes |
Number Of Burners |
4.00 |
Hot Surface Indicator Lights |
YES |
Installation Type |
Self Rimming or Flush Installation |
Material |
Ceramic Tempered Glass |
Cooktop Surface Style |
Glass-Top |
Total BTUs |
NA |
Auto Shut Off |
Yes |
Child Lock |
Yes |
Approved for Commercial Use |
No |
Commercial |
No |
Continuous Grates |
YES |
Downdraft Ventilated |
Yes |
Griddle |
No |
Grill |
No |
Ignition Type |
Electric |
Outdoor Approved |
No |
Power Burner |
No |
Sabbath Mode |
No |
Smart Home |
No |
WIFI APPROVED |
No |
Fingerprint Resistant Finish |
No |
Bridge Element |
Yes |
Pan Recognition Sensor |
Yes |
Warm Function |
Yes |
App Compatibility |
NO |
Wireless Communication |
NO |
ELECTRIC (VOLTS) |
220 V/60 Hz |
AMPERAGE |
32.00 |
HERTZ |
61 Hz |
EXHAUST VERSION |
Convertible with Kit |
DIMENSIONS |
76 x 57 x 26 |
DIMENSIONSinches |
30 5/16" x 22 9/16" x 10 3/16" |
Depth |
22 9/16" |
Height |
10 3/16" |
Width |
30 5/16" |
Cutout Depth |
21 1/8" |
Cutout Height |
10 3/16" |
Cutout Width |
28 3/4" |
Wattage |
7.70 |
Back Left Burner Watts |
3700.00 |
Back Middle Burner Watts |
NA |
Back Right Burner Watts |
3700.00 |
Front Left Burner Watts |
3700.00 |
Front Middle Burner Watts |
NA |
Front Right Burner Watts |
3700.00 |
Middle Burner Watts |
NA |
Transition Conversion Fitting |
NA |
Recirculating Kits |
KIT0192765 |
Certifications |
ADA, UL, cUL. |
ADA |
YES |
CEC Approved for CA Sale |
YES |
Title 20 Compliant |
YES |
Energy Star |
NO |
Certification NOM |
Activo |
