Warranty |
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com |
SHIPPING WEIGHT (kg) |
21.20 |
NET WEIGHT (kg) |
16.00 |
CARTON LENGHT (mm) |
870.00 |
CARTON HEIGHT (mm) |
673.00 |
CARTON WIDTH (mm) |
458.00 |
VOLUMEN (M3) |
0.30 |
SHIPPING WEIGHT |
46.74 |
NET WEIGHT |
35.27 |
CARTON LENGHT |
34.25 |
CARTON HEIGHT |
26.50 |
CARTON WIDTH |
18.03 |
COUNTRY OF MANUFACTURE |
MX |
QTY PACKAGE |
1.00 |
INTENDED APPROVED USE |
Residential use |
Finish |
Stainless Steel + Glass |
Color |
inox + glass |
Type of Ventilation |
Convertible |
HOODS FEATURES |
3x layer mesh,Led light,CFM reduction system |
WIDTH (IN) |
30" |
WIDTH (CM) |
76.00 |
AIRFLOW (M3/H) |
680.00 |
CFM (MAX) |
400.00 |
db (min) |
15.00 |
db (max) |
51.00 |
SONES |
0.4 - 5.0 |
EXHAUST VERSION |
Convertible with Kit |
EXHAUST SIZE |
Round 6" |
DUCT SHAPE |
Round |
EXHAUST LOCATION |
Top Only |
RECTANGULAR DUCTH HEIGHT |
NA |
RECTANGULAR DUCT WIDTH |
NA |
Round duct diameter |
6" |
ELECTRIC (VOLTS) |
120 V/60 Hz |
AMPERAGE |
2.5 A |
HERTZ |
60.00 |
WATTS |
301.00 |
LIGHTING |
LED 2 x 2.1 ww 3000 KK |
BULB TYPE |
LED |
BULB INCLUDED |
YES |
NUMBER OF LIGHTS |
2.00 |
BULB WATTS |
2.10 |
KELVINS |
3000.00 |
GREASE FILTER TYPE |
Dishwasher-Safe, Anodized Aluminum Mesh Filter |
DISHWASHERSAFE FILTER |
YES |
FILTER MATERIAL |
Aluminum Mesh |
BLOWER TYPE |
Interior Unit |
CONTROL TYPE |
Electronic Touch Controls with Adjustable Color Backlight |
SPEED CONTROL |
YES |
NUMBER OF SPEEDS |
4.00 |
REMOTE CONTROL |
NO |
POWER SOURCE |
Hardwired |
OUTDOOR USE |
NO |
SMUDGE RESISTANT |
NO |
RECIRCULATION KIT NEEDED |
YES |
CFM REDUCTION |
Yes |
DIMENSIONS |
76 cm x 50 cm x 61 cm |
DIMENSIONSinches |
30" x 19 11/16" x 20 3/8" |
ADJUSTABLE HEIGHT |
YES |
Minimum Overall Height - Top to Bottom |
20 3/8" |
Maximum Overall Height - Top to Bottom |
36 5/8" |
Overall Height - Top to Bottom |
36 5/8" |
Overall Width - Side to Side2 |
30" |
Overall Depth - Front to Back |
19 11/16" |
Hood Height |
1 15/16" |
Minimum Compatible Ceiling Height |
6'9" |
Maximum Compatible Ceiling Height |
9'0" |
Minimum Height Above Cooktop (ELECTRIC) |
= 24 |
Minimum Height Above Cooktop (GAS) |
= 30 |
Maximum Height Above Cooktop |
36" |
Chimney Width - Side to Side |
13 1/32" |
Chimney Depth - Front to Back |
10 3/4" |
Chimney Height - Top to Bottom |
32 7/8 |
RECIRCULATION KIT NUMBER |
KIT0102875 |
CHIMNEY EXTENSION NUMBER |
KIT0100315/KIT01609-1 |
TELESCOPIC DUCT COVER |
- |
DUCT TRANSITION |
- |
TRANSITION REDUCER KIT |
- |
BACKDRAFT DAMPER |
- |
NON RETURN VALVE |
- |
UPGRADE FILTER |
GF04YB |
CFM REDUCTION KIT |
- |
BACKSPLASH KIT |
- |
INTERNAL BLOWER |
- |
INLINE BLOWER |
- |
EXTERNAL BLOWER |
- |
INLINE BLOWER SHELL KIT |
- |
EXTERNAL BLOWER SHELL KIT |
- |
HEAT LAMPS |
- |
SPACER/LINER |
- |
WALL MOUNT BRACKET |
- |
HIGH CEILING EXTENSION KIT |
- |
REMOTE CONTROL KIT |
- |
cUL listed |
YES |
UL listed |
YES |
AHAM verified |
NO |
TITLE 24 |
NO |
Prop65Disclosure |
YES |
ENERGY STAR |
NO |
WIFI CAPABLE |
NO |
COMERCIAL USE APPROVED |
NO |
ADA COMPLIANT |
NO |
APP CAPABLE |
NO |
VENTILATION DIRECTION |
HORIZONTAL |
SMART COMPATIBLE |
NO |
FITLER INDICATOR LIGHT |
NO |
HEAT SENSOR |
NO |
CHAROCAL FILTER |
YES |
VERSION ADVANCES |
Button change |
CERTIFICADO NOM |
NA |
