FFEC3025UB Frigidaire 30" Electric Cooktop FFEC3025UB

The Frigidaire 30 in. Electric Cooktop has two different element sizes, and alerts you when the cooktop is on and is too hot to touch. This frameless drop-in cooktop has easy-to-use controls that make it easy to select cooking temperatures and options.

Product Line	Electric Cooktop
Power Type	Electric 240v
Size	30"
Installation Type	Drop-In
Factory	Rayong
Color	Black
Cooktop
Cooking Surface Type	Smooth
Hot-Surface Indicator Light	Yes
Cooktop Performance
Right Front Element Burner Size (Small)	6"
Right Front Element Burner Size (Large)	9"
Right Rear Element Burner Size	6"
Left Front Element Burner Size	6"
Left Rear Element Burner Size	9"
Right Front Element Burner (Small)	1600 Watts
Right Front Element Burner (Large)	3000 Watts
Right Rear Element Burner	1200 Watts
Left Front Element Burner	1200 Watts
Left Rear Element Burner	2500 Watts
Controls
Sabbath Mode	No
Display
Control Location	Right
Display Type	Mechanical
Dimensions and Volume
Height	2 5/8"
Width	30 5/8"
Depth	21 3/8"
Electrical Specifications
Amps @ 240 Volts	32.9 Amps
Connected Load @ 240V	7.9 kW
Minimum Circuit Required	40 Amps
Voltage Rating	240 V
General Specifications
Frigidaire Fit Promise	Yes
Product Weight	29.45 lbs
Prop 65 Label	Yes
Warranty - Labor	1 Year
Warranty - Parts	1 Year
AB-1200	Information available at frigidaire.com/en/ab1200
Installation
Installed Over a Wall Oven	Yes
Power Supply Connection Location	Right Center
Certifications and Approvals
ADA Compliant	No
CSA Listed	Yes
ETL Listed	No
UL Listed	Yes
