Frigidaire Gallery 36" Gas Cooktop FGGC3645QB

The Frigidaire Gallery 36 in. Drop-In Gas Cooktop has 5 sealed gas burners including an 18,000 BTU Quick Boil Burner that boils water faster and a Simmer Burner that is perfect for delicate foods. It also has dishwasher-safe, continuous grates that make it easy to move heavy pots and pans between burners without lifting. The all-new design features angled front controls that are easy to use and seamless recessed burners.

Product Line	Gas Cooktop
Power Type	NG
Size	36"
Installation Type	Drop-In
Factory	Rayong
Color	Black
Installation
Gas Supply Connection Location	Right Center
Installed Over a Wall Oven	Yes
LP Conversion Kit Included	Yes
Power Supply Connection Location	Right Center
Electrical Specifications
Minimum Circuit Required	5 Amps
Voltage Rating	120 V
Certifications and Approvals
ADA Compliant	Yes
Cooktop
Grate Finish	Matte Black
Grate Material	Cast Iron
Grate Quantity	3
Grate Style	Continuous
Dimensions and Volume
Height	5"
Width	36"
Depth	21 3/4"
Safety Certifications and Approvals
CSA Listed	Yes
Controls
Sabbath Mode	No
General Specifications
Product Weight	56.05 lbs
Prop 65 Label	Yes
Warranty - Labor	1 Year
Warranty - Parts	1 Year
Exterior
Knob Color	Color Coordinated
Cooktop Performance
Right Front Element Burner	12,000 BTU
Right Rear Element Burner	5,000 BTU
Left Front Element Burner	9,500 BTU
Left Rear Element Burner	9,500 BTU
Center Element Burner	18,000 BTU
Display
Control Location	Front
