JD630DTWW GE® 30" Drop-In Electric Range JD630DTWW
JD630DTWW GE® 30" Drop-In Electric Range
- 9"/6" Power Boil element
- Self-clean oven
- Ceramic glass cooktop
- Black gloss oven interior
- Dual-element Bake
- Electronic oven controls
9"/6" Power Boil element
Produces rapid, powerful heat
Self-clean oven
Cleans the oven cavity without the need for scrubbing
Ceramic glass cooktop
Smooth cooktop easily wipes clean
Black gloss oven interior
Enjoy a clean and sleek appearance
Dual-element Bake
Upper and lower elements produce even heat and great results
Electronic oven controls
Electronic touch pads are easy to operate
Produces rapid, powerful heat
Self-clean oven
Cleans the oven cavity without the need for scrubbing
Ceramic glass cooktop
Smooth cooktop easily wipes clean
Black gloss oven interior
Enjoy a clean and sleek appearance
Dual-element Bake
Upper and lower elements produce even heat and great results
Electronic oven controls
Electronic touch pads are easy to operate
CAPACITY | |
Total Capacity (cubic feet) | 4.4 cu ft |
APPEARANCE | |
Oven Door Features | Big View Oven Window Glass Door |
Handle | Designer Style |
Installation | Flush Appearance |
Control Knobs | Color-Matched Weighted |
Handle Color | White |
Color Appearance | White on White |
POWER / RATINGS | |
KW Rating at 240V | 11.9 |
Bake Wattage | 3410W |
Amp Rating at 208V | 40 |
Broiler Wattage | 3420W |
KW Rating at 208V | 8.9 |
Amp Rating at 240V | 40 |
WARRANTY | |
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance |
Warranty Notes | See written warranty for full details |
WEIGHTS & DIMENSIONS | |
Net Weight | 152 lb |
Depth Without Handle | 25.75 in |
Oven Interior Dimensions (W x H x D) (in.) | 24 x 17-1/2 x 18-1/4 |
Cooktop Width | 31.25 in |
Depth with Door Open | 44.625 in |
Cabinet Opening | 30 in |
Cabinet Width | 30 in |
Approximate Shipping Weight | 179 lb |
Overall Width | 31.25 in |
Overall Depth | 28.5 in |
Overall Height | 27 in |
FEATURES | |
Element - Right Front | 9"/6" 3000W Power Boil |
Oven Features | 6-Pass Bake Element 6-Pass Broil Element |
Interior Oven Light | 1 Incandescent |
Fuel Type | Electric |
Melt Setting | Yes |
OU Certified | No |
Oven Control Features | Audible Preheat Signal Auto Oven Shut-Off with Override Certified Sabbath Mode Control Lock Capability C° or F° Programmable Delay Bake Option With Cook & Hold Electronic Clock & Kitchen Timer |
Cooktop Burner Type | Radiant Smoothtop |
Oven Rack Features | 2 Oven Racks |
Element - Left Front | 8" 2000W |
Oven Cleaning Type | Self-Clean |
Hot Surface Indicator Lights | 4 |
Product Type | Drop-In |
Heating Element "ON" Indicator Light | 2 |
Cooktop Type | Radiant Smoothtop |
Element - Left Rear | 8" 2000W |
Sabbath Mode | Yes |
Element - Right Rear | 6" 1200W |
Cooktop Surface | Overhanging Cooktop White Patterned Ceramic Glass |
Control Location | Front |
Oven Rack Positions (Single or Upper/Lower) | 7 |
Control Type | Digital Temperature Display Electronic Touchpads |
Self-Clean Oven Door Lock | Automatic |
Cooking Technology | Traditional |
