JM250DTBB GE® 27" Drop-In Electric Range JM250DTBB

Self-clean oven
Cleans the oven cavity without the need for scrubbing

Sensi-temp technology
Enjoy the same cooking power as a traditional coil with an added safety feature that meets the new UL858 Household Electric Ranges Standard for Safety

Chrome drip bowls
Contain spills and remove for easy cleaning

Electronic clock and timer
Help cooks coordinate meal preparation and cooking

CAPACITY
Total Capacity (cubic feet)	3 cu ft
APPEARANCE
Oven Door Features	Big View Oven Window Glass Door
Handle	Designer Style
Installation	Flush Appearance
Control Knobs	Color-Matched
Handle Design	D-shaped
Handle Color	Black
Color Appearance	Black
POWER / RATINGS
KW Rating at 240V	10.6
Bake Wattage	2000W
Amp Rating at 208V	40
Broiler Wattage	3400W
KW Rating at 208V	8.0
Amp Rating at 240V	40
WARRANTY
Labor Warranty	Limited 1-year entire appliance
Parts Warranty	Limited 1-year entire appliance
Warranty Notes	See written warranty for full details
WEIGHTS & DIMENSIONS
Net Weight	104 lb
Depth Without Handle	24.1875 in
Oven Interior Dimensions (W x H x D) (in.)	19 x 15 x 18
Cooktop Width	27.125 in
Depth with Door Open	44.1875 in
Cabinet Opening	27 in
Cabinet Width	27 in
Approximate Shipping Weight	124 lb
Overall Width	27.125 in
Overall Depth	27.1875 in
Overall Height	28.4375 in
FEATURES
Element - Right Front	6" 1250W 4-turn
Oven Features	4-Pass Bake Element 4-Pass Broil Element
Removable One-Piece Drip Bowls	Chrome
Interior Oven Light	1 Incandescent
Fuel Type	Electric
Oven Interior	Gray
Oven Control Features	Audible Preheat Signal Auto Oven Shut-Off Delay Bake Option (Time Bake) Electronic Clock and Timer
Cooktop Burner Type	Coil
Oven Rack Features	2 Oven Racks
Element - Left Front	8" 2400W 5-turn
Oven Cleaning Type	Self-Clean
Product Type	Drop-In
Heating Element "ON" Indicator Light	Yes
Cooktop Type	Coil
Element - Left Rear	6" 1250W 4-turn
Element - Right Rear	6" 1250W 4-turn
Cooktop Surface	Lift-Up Overhanging Cooktop Porcelain Enamel
Control Location	Front
Oven Rack Positions (Single or Upper/Lower)	4
Control Type	Digital Temperature Display Electronic Touchpads
Self-Clean Oven Door Lock	Automatic
Cooking Technology	Traditional
