- 2.1 cu. ft. capacity
- Chef Connect
- Bottom control with integrated handle
- Four-speed, 400CFM venting system
- 10 power levels
- "Add 30 seconds" button
- Turntable On/Off
- Sensor cooking controls
- 10 Power Levels for Every Dish
2.1 cu. ft. capacity
1000 Watts (IEC-705 test procedure)
Chef Connect
Three options with a single touch. For instant convenience, choose when to automatically sync clocks and the range elements with the microwave's surface light and vent
Bottom control with integrated handle
Enjoy a sleek appearance that makes cleaning easy
Four-speed, 400CFM venting system
Removes smoke, steam and odors
10 power levels
Multiple power levels offer cooking flexibility
"Add 30 seconds" button
Add 30 seconds of microwave cooking time
Turntable On/Off
Controls turntable operation
Sensor cooking controls
Automatically adjusts time and power for delicious cooking results
10 Power Levels for Every Dish
From energizing morning beverages to delicate sauces, tailor your heating precision. Achieve perfection across from spectrum, from high heat to low heat.
1000 Watts (IEC-705 test procedure)
Chef Connect
Three options with a single touch. For instant convenience, choose when to automatically sync clocks and the range elements with the microwave's surface light and vent
Bottom control with integrated handle
Enjoy a sleek appearance that makes cleaning easy
Four-speed, 400CFM venting system
Removes smoke, steam and odors
10 power levels
Multiple power levels offer cooking flexibility
"Add 30 seconds" button
Add 30 seconds of microwave cooking time
Turntable On/Off
Controls turntable operation
Sensor cooking controls
Automatically adjusts time and power for delicious cooking results
10 Power Levels for Every Dish
From energizing morning beverages to delicate sauces, tailor your heating precision. Achieve perfection across from spectrum, from high heat to low heat.
CAPACITY | |
Total Capacity (cubic feet) | 2.1 cu ft |
Vent CFM | 400 |
FILTER | |
App Filter - Control Type | Electronic touchpad |
App Filter - Wattage | 1000 to 1099 |
App Filter - Cabinet Width | Cooking 30 in. (Standard) |
App Filter - Product Type | Microwave Over-the-Range |
App Filter - Capacity | Microwave Large (1.9 cu. ft. and above) |
App Filter - Voltage | 120V |
App Filter - Convection | No |
App Filter - Venting Type | External |
App Filter - Cooking Technology | Microwave Only |
APPEARANCE | |
Door Swing | Hinges on Left |
Handle Color | Fingerprint Resistant Black Stainless |
Oven Door Features | Oven Window |
Installation | Easy Mount |
Door Color | Black Stainless |
Case Color | Gray |
Handle | Integrated |
Color Appearance | Fingerprint Resistant Black Stainless |
POWER / RATINGS | |
Input Volts/Hertz | 120/60 |
Electrical Input - 120V Amperage | 14.5 |
Electrical Input - 120V Watts | 1700 |
WARRANTY | |
Labor Warranty | Limited 1-year entire appliance |
Parts Warranty | Limited 1-year entire appliance Limited 5-year magnetron tube |
Warranty Notes | See written warranty for full details |
ECONOMICAL / QUIET | |
Non-Vented | Convertible to Recirculating (Filter Included) |
Venting Type | Externally Vented (Factory Set) |
ACCESSORIES | |
Optional Side Filler Panel Kit | JX36BTS |
Optional Kits | 15" Bump Out Kit - JX15BUMPBB |
Recirculating Charcoal Filter Kit | WB06X10807 (included) |
WEIGHTS & DIMENSIONS | |
Approximate Shipping Weight | 65 lb |
Cabinet Width | 30 in |
Net Weight | 58 lb |
Exterior Height (Front) | 15.6875 in |
Depth with Door Open | 45.375 in |
Overall Width | 29.875 in |
Cutout Width (in) | 30 |
Cutout Depth (in) | 13 |
Cutout Height (in) | 16.5 |
Overall Depth | 15.5625 in |
Overall Height | 16.5625 in |
Exterior Height (Rear) | 16.5625 in |
Cavity (W x H x D) | 21-15/16 x 11-5/8 x 14-9/16 |
FEATURES | |
Display Type | LED |
Microwave Sensor Cooking Controls | Auto Cook Defrost Popcorn Potato Reheat Steam Cook |
Electronic Digital Display with Clock | Scrolling (LED with icons) |
Display Screen Size (Diagonal Length) | 3.13 |
Cooking Modes | Microwave |
Control Location | Bottom Controls |
Style | Over-The-Range |
Microwave Watts (IEC-705) | 1000 W |
Turntable On / Off | Yes |
Power Levels | 10 |
Control Type | LED |
Cooktop Lighting | Halogen High/Low/Off |
Control Features | Add 30 Seconds Cancel/Off Chef Connect Cook Time Express Cook Lock Controls Power Level Set Clock Settings Start/Pause Surface Light Timer On/Off Turntable On/Off Vent Fan |
Product Type | Over-the-range Microwave |
Sound Volume Control | Yes |
Turntable | Glass |
Range Communication | Connected |
Cooking Technology | Microwave |
Exhaust Fan | 4-Speed Including Boost 400-CFM |
Vent | Back Front Top |
Turntable Size | 14.2 in |
Interior Oven Light | Halogen |
