Ge Appliances UVC9480SLSS 48" Custom Hood Insert UVC9480SLSS

LED Hood Light
Get a bright view of your cooktop as you prepare your favorite meals with LED lighting in this range hood

1200 CFM Range Hood Blower Motor
This high-CFM range hood offers powerful ventilation that keeps your kitchen fresh and free of cooking fumes and odors

Built-In WiFi
This smart range hood lets you adjust vent speed and turn on lights using your phone, for the ultimate in kitchen convenience

ADA Compliant
This ADA compliant range hood can be operated with a mobile device, eliminating reaching and improving safety for users of all abilities

Baffle Filters
The baffle filters in this range hood trap more grease and require less frequent cleaning than standard filters

Chef Connect
Synchronize your oven and GE Appliances hood insert so the hood turns on when the cooktop turns on and the lights illuminate when a burner is activated

Backlit Push Button Controls
Easily operate this range hood with push buttons that are illuminated from behind and simple to find and reach

4-Speed Fan
Have strong ventilation at four fan speeds that you can adjust to match your cooking techniques

Night Light Setting
Turn on the range hood night light setting for a soft glow in the kitchen at night

Heat Sensor
This temperature sensor range hood will automatically turn on if the heat sensor detects high temperatures, preventing damage by reducing heat

Customizable Fit
The included side panels are designed to seamlessly attach to the hood insert, allowing it to perfectly fit into a 45" cutout.

FILTER
App Filter-Multi Brand	Cafe GE Monogram
App Filter - Hood Type	Custom Hood Insert
App Filter - Venting Type	Convertible
APPEARANCE
Custom Insert	Yes
Design Style	Custom
Color Appearance	Stainless Steel
POWER / RATINGS
Amp Rating at 120V	6.0
WARRANTY
Labor Warranty	Limited 1-year entire appliance
Warranty Notes	See written warranty for full details
Parts Warranty	Limited 1-year entire appliance
ACCESSORIES
Optional Accessories	JXHC1 - Power Cord Kit
WEIGHTS & DIMENSIONS
Cabinet Width	48 in
Overall Width with side panels installed	46 1/2 in
Net Weight	97 lb
Overall Depth	21.875 in
Approximate Shipping Weight	121 lb
Overall Height	12.5 in
Overall Width	39.625 in
FEATURES
Cooktop Lighting	4 LED
WiFi Connect	Built-In
Max CFM	780
Required Duct Size	10-in. Round
CFM/ Sones Rating	780/7.0 (Boost speed) - Vertical venting
Time Delay Shut-Off	Yes
Exhaust Options	10" Round Duct Vertical
Lighting	LED On/Off/Night Light
Product Type	Custom Hood Insert
Control Features	Delay Off Fan Speed (+) (-) Fan Speed Boost Heat Sensor Light Off/On/Night Light Power On/Off Time to clean filter warning (in app feature)
Vertical Exhaust Blower Rating (CFM)	1220
Remote Control	Yes
Sones Rating : Top Exhaust-Round	10.0
Variable Speed Fan	Yes
Control Type	Backlit Pushbutton
Baffle Stainless Steel Filters	4
Dual Blowers	Yes
Removable Filter	Yes
Charcoal Filter	Yes
Recirculating Capable	No
Blower Levels	4 Including Boost
