KITCHENAID KSDV730TPS
Authorized Reseller
Kitchenaid KSDV730TPS 30-Inch 4-Burner Dual Fuel Downdraft Slide-In Range
Kitchenaid KSDV730TPS 30-Inch 4-Burner Dual Fuel Downdraft Slide-In Range
Item Not Available
Couldn't load pickup availability
Check Delivery:
- Cook multiple dishes at once with a 6.4 cu. ft. total capacity
- 6.4 cu. ft. total capacity
- EVEN-HEAT True Convection for consistent baking and roasting
- External or Recirculating Venting Options to fit your kitchen
- Steam Bake mode plus the included tray adds additional moisture during baking
This all-in-one dual fuel range includes Downdraft, which integrates the ventilation system so a separate hood is not needed. Smoke and odors can be removed outside or filtered air can be recirculated inside. This range also features flawless cooking results from Even-Heat™ True Convection, featuring a unique bow-tie design with a heating element and fan that circulates hot air throughout the entire oven, providing consistent temperatures for crisp, flaky baked goods, juicy, well-browned roasts and flavorful caramelized vegetables.
| Certifications | |
| Ada Compliant | Yes |
| Cul | Yes |
| Energy Rating | 393 |
| Prop65 | CA |
| Star K Certified | No |
| Ul | Yes |
| Controls | |
| Display Color | Blue; Red; White |
| Cooktop Details | |
| Auto Re-ignition | No |
| Cooktop Control Knob Type | Weighted-Plastic |
| Cooktop Control Location | Front |
| Cooktop Control Type | Knobs |
| Cooktop Surface Color | Stainless |
| Cooktop Surface Material | Stainless Steel |
| Griddle Included | No |
| Heating Element On Indicator Light | No |
| Hot Surface Indicator Light | No |
| Ignition Type | Electronic |
| Details | |
| Air Fry | Yes |
| Automatic Convection Conversion Temperature Adjust | Yes |
| Cooktop Configuration | All Burners |
| Delay Clean | No |
| Fingerprint Resistant | Yes |
| Fuel Type | Dual Fuel |
| Installation Configuration | Freestanding |
| Lp Convertible | Yes |
| Oven Automatic Shut-off | Yes |
| Oven Configuration | Single Oven |
| Oven Light Switch Location | Oven Control |
| Oven Selections | Proofing |
| Power On Indicator Light | Yes |
| Power Outage Compatible | No |
| Range Configuration | Slide-In |
| Range Drawer Type | None |
| Range Type | Slide-in |
| Dimensions | |
| Product Height | 36.0 |
| Carton Height | 43 |
| Gross Weight | 205 |
| Oven Interior Height | 22.125 |
| Carton Width | 32 |
| Product Depth | 28.875 |
| Oven Interior Depth | 20.75 |
| Depth With Door Open 90 Degree | 48.75 |
| Depth Excluding Doors | 25.563 |
| Adjustable Height | Yes |
| Cutout Depth | 28.875 |
| Cutout Height | 36 |
| Depth Closed Excluding Handles | 26.375 |
| Depth Closed Including Handles | 28.875 |
| Carton Depth | 30.5 |
| Cutout Width | 30 |
| Oven Interior Width | 24.125 |
| Net Weight | 189 |
| Product Width | 29.875 |
| Electrical | |
| Power Cord Included | Yes |
| Element/burner Details | |
| Cooktop Element Style | Gas Burner |
| Left Front Element-burner Power | 17,000 BTU |
| Left Front Element-burner Type | Sealed Burner |
| Left Rear Element-burner Power | 5,000 BTU |
| Left Rear Element-burner Size | N/A |
| Left Rear Element-burner Type | Sealed Burner |
| Number of Cooking Element-burners | 4 |
| Right Front Element-burner Power | 15,000 BTU |
| Right Front Element-burner Size | N/A |
| Right Front Element-burner Type | Sealed Burner |
| Right Rear Element-burner Power | 9200 BTU |
| Right Rear Element-burner Size | N/A |
| Right Rear Element-burner Type | Sealed Burner |
| Export Details | |
| Export Packaging | No |
| Exterior Details | |
| Door Type | Metal & Glass |
| Handle Color | Stainless Steel |
| Handle Material | Stainless Steel |
| Handle Type | Towel Bar |
| Knob Color | Stainless Steel |
| Knob Type | Weighted-Plastic |
| Oven Control Location | Front |
| Oven Control Type | Tap Touch |
| Oven Window Size | Large |
| General | |
| Air Fry Basket Included | No |
| Literature Language | English and French |
| Range Features | ADA Compliant; Air Fry; Auto Convect Conversion; Baking Drawer; Downdraft; EasyConvect™ Conversion; Even-Heat™ True Convection; FIT System; Sabbath Mode/Star-K Certification; Steam Clean; Steam Rack; True Convection |
| Grate Details | |
| Grate Details | Cast Iron Grates |
| Number of Grates | 3 |
| Oven Details | |
| Bake Element Power | 3,600 W |
| Broiler Element Power | 4000W |
| Broiler Location | Top of Oven |
| Convection Element Power | 900 |
| Convection Element Type | True Bow Tie |
| Convection Functions | No Preheat Air Fry |
| Door Lock | No |
| Door Removable | Yes |
| Hidden Bake Element | Yes |
| Interior Color | Black |
| Natural Gas Convertible | Yes |
| Number of Oven Lights | 2 |
| Number of Oven Racks | 2 |
| Number of Rack Guides | 7 |
| Oven Cleaning Type | Steam Clean |
| Oven Cooking System | True Convection |
| Oven Ignition Type | Electronic |
| Oven Light Type | Halogen |
| Oven Rack Front Material | Metal |
| Oven Rack Guide Type | Embossed |
| Oven Rack Type | 1 Heavy Duty and 1 Steam Rack |
| Temperature Probe | No |
| Temperature Sensor | No |
| Smart Compatibility | |
| Connectivity | No |
| Smart Appliance | No |
| Works With | No |
| Ventilation Details | |
| Maximum Motor Cfm | 300 |
