Summit ASDR1524 15" Wide 2-drawer All-refrigerator, ADA Compliant ASDR1524

SKU/Model #: ASDR1524
Summit ASDR1524 15" Wide 2-drawer All-refrigerator, ADA Compliant
Authorized Reseller
SKU/Model #: ASDR1524
Summit ASDR1524 15" Wide 2-drawer All-refrigerator, ADA Compliant
Free Shipping
$1,738.00
List Price:
Instant Savings:
  • 15" wide 1.7 cu.ft. all-refrigerator with two gliding drawers
  • Unique 17.88" shallow depth is ideal for wet bars, island kitchens, and other undercounter areas with limited footprint space
  • Sized just under 32" high to allow installation under lower ADA compliant counters
  • Leveling legs can be extended up to 2", with a slide-out kickplate that allows you to raise the overall height from 32" up to 34" if used under more standard sized cabinets
  • Front-breathing design allows you to make the best use of space by installing your appliance under the counter and flush with other cabinets in 15" wide openings
  • Drawer interiors and exteriors are fully constructed from 304 grade stainless steel for lasting durability with a finished front for an elegant look
  • Drawers can be customized with overlay panels sized (at 14.75" W x 14.1" H at 3/4" thick) to match or accent existing cabinetry
  • Stainless steel handles add style to any setting
  • No-frost operation for minimal user maintenance
  • Electronic controls located on the top drawer ensure intuitive temperature management, with an external readout that can switch from Celsius to Fahrenheit at the touch of a button
  • Elegant LED lighting in a gentle white hue illuminates the top drawer for an easy view of the interior
  • Two adjustable dividers provide flexibility when organizing the interiors
  • Alarm alerts you if the unit s temperature goes beyond recommended high and low temperature ranges
  • Audible alarm will sound if either drawer is left open longer than one minute
  • Optional setting lets you disable the lighting and alarm for up to 48 hours during periods of observance
  • Disables digital controls after two minutes of activity for added safety
  • Unit will restore the most recent temperature settings after losing power
  • Optional feature disables alarms, interior light, and displays for up to 96 hours
  • Design allows you to plug the unit in flush against the wall socket with no need to add extra depth
  • Space-saving design with no exposed coils for easier cleanability
  • Allows the unit to be used freestanding
  • Provides for efficient, even cooling of the entire unit
  • Unit will retain temperature settings after losing power
  • Included and recommended for user-installation to reduce the risk of tipping
  • ETL-S listed to NSF-7 standards to allow use in commercial establishments
  • Environmentally friendly design with no ozone-damaging chemicals
  • Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Summit's shallow depth series of built-in undercounter refrigeration brings full functionality to kitchen islands, wet bars, and other settings with space limitations. Model ASDR1524 is a 15" wide 2-drawer refrigerator sized under 18" deep. It comes in a 32" height to fit under lower ADA compliant counters, with adjustable legs and a sliding kickplate cover that also allows you to raise the overall height up to 34" to fit standard counter spaces. The front-breathing system allows built-in installation, while the fully finished black cabinet also allows freestanding use. This unit has a sealed rear and right angle cord for a better fit. The drawer fronts are fully finished in stainless steel, but can also accept panel overlays for a custom look (panel dimensions: 14.75" W x 14.1" H at 3/4" thick). Sleek stainless steel handles are included. Frost-free operation ensures minimal user maintenance, with fan-forced cooling to evenly distribute the temperature. A digital thermostat, located atop the upper drawer, makes it easy to manage the temperature, with an LED display that can be read in Celsius or Fahrenheit. Two removable dividers allow you to separate the drawer compartments for more versatile storage. White LED lighting makes it easy to view stored contents in the top drawer. A child lock will disable the digital controls after two minutes of inactivity to prevent accidental adjustments. Additional features include audible alarms for high-temperature fluctuations and open drawer alerts, a temporary memory function to recover all settings in the event of power loss, and sabbath mode to disable certain electrical features during periods of religious observance. The ASDR1524 refrigerator is ETL-S listed to NSF-7 commercial standards but can also be used in the home. With its deluxe style, user-friendly features, and uniquely shallow depth, this unit offers premium value for a variety of settings. Additional 18" deep choices are available in a variety of styles, including 15", 19", and 24" widths, as well as outdoor refrigerators, wine cellars, and more.
Overview
Height of Cabinet 32.0" (81 cm)
Width 14.75" (37 cm)
Depth 17.88" (45 cm)
Depth with Handle 19.0" (48 cm)
Depth with door at 90° 29.63" (75 cm)
Capacity 1.7 cu.ft. (48 L)
Defrost Type Frost-Free
Door Stainless Steel/Panel-Ready
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Energy Usage/Year 235.0kWh/year
Amps 1.0
Voltage/Frequency 115 V AC/60 Hz
Weight 65.0 lbs. (29 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101079530
Refrigerator Features
Sabbath Mode Yes
Door Swing Drawer
Height Adjustable Yes
Thermostat Type Digital
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 0.64oz.
High Side PSI 270.0
Low Side PSI 105.0
Level Legs Qty 4
Interior Light Yes
Interior Drawers Yes
Interior Drawers Qty 2
Temperature Range 36 to 43 F
Sound Level 32.9 dB
Drawer Dimensions
Interior Height 1 8.0" (20 cm)
Interior Width 1 9.0" (23 cm)
Interior Depth 1 11.25" (29 cm)
Interior Height 2 8.0" (20 cm)
Interior Width 2 9.0" (23 cm)
Interior Depth 2 11.25" (29 cm)
Dimensions
Compressor Step Height 3.75" (10 cm)
Compressor Step Width 9.0" (23 cm)
Compressor Step Depth 4.75" (12 cm)
