Summit SWC007H34PNRLHD 6" Wide Built-in Wine Cellar (panel Not Included) SWC007H34PNRLHD
Discontinued
Summit SWC007H34PNRLHD 6" Wide Built-in Wine Cellar (panel Not Included)
$891.80
- Single zone wine cellar sized for built-in installation in 6" wide spaces
- Specialized hinges allow you to install an overlay panel over the door trim to create a custom look that matches adjacent cabinetry (panel size: 28 1/8" H x 5 5/8" W at 3/4" thickness)
- Uniquely slim fit lets you transform extra cabinet space into a 7-bottle wine storage center
- Make the best use of space by installing your appliance under the counter
- Meets UL-471 commercial standards
- Leveling legs can be adjusted to raise the height up to 34.25" for an appropriate fit under standard counters
- Double pane tempered glass provides a full display of your collection
- Electronic controls for precise temperature management
- Interior can hold up to 7 Bordeaux style bottles. Most wider Burgundy style bottles fit as well
- The floor slight is slightly angled, allowing you store one bottle that has been uncorked at a gentle tilt
- Temperature readout can be shown in Celsius or Fahrenheit
- Provides an attractive and efficient bottle display
- Reduced maintenance and steady temperature performance
- Interior fan helps to ensure the temperature is evenly distributed
- Audible alarm will sound if the door is left ajar for over 60 seconds
- If the interior temperature becomes too warm, an audible alarm will sound and the temperature display will flash until the proper temperature is restored
- Optional setting lets you disable the lighting and alarm for up to 48 hours
- Unit will retain last temperature settings in the event of a power failure
- Flat design offers added space savings by requiring no extra depth to plug the unit in
- Space saving design with easier cleanability
- Includes an extra kickplate to cover up the leveling legs if the unit's height is raised
- Runs at under 34 dB for a quiet performance in any setting
- Compressor-based operation to ensure reliable temperature performance
- For this unit with the door opening from the other side, see model SWC007H34PNR
- Environmentally friendly design with no ozone-damaging chemicals
- Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Summit lets you transform even the slimmest undercounter space into a fully functional wine cellar with our 6 inch wide SWC007H34PNR. Designed for built-in installation, the SWC007H34PNRLHD features a front-breathing compressor-based cooling system to ensure proper wine temperature is maintained. The double pane tempered glass door comes with specialized hinging that lets you install your own custom panel over the frame, allowing you to match or complement surrounding cabinetry (panel dimensions: 28 1/8" H x 5 5/8" W at 3/4" thickness). This unit has a right angle plug and sealed rear for added space savings. For this unit with a right hand door swing, see model SWC007H34PNR. Inside, the SWC007H34PNRLHD features a digital thermostat with easy touch controls and a temperature readout that can be viewed in Celsius or Fahrenheit at the touch of a button. The temperature can be set between 41 and 72 F to suit red or white wine. Seven slots let you store wine bottles with ease. The floor is set at a slight angle, ideal for holding an open bottle. This unit is equipped with an open door and high temperature alarm for added assurance. The Sabbath mode setting allows you to disable certain electrical features during periods of observance. The commercial grade compressor operates quietly, keeping the sound levels under 34 dB. With its innovative size and customizable design, the SWC007H34PNRLHD can be installed in virtually any space to bring reliable wine storage to kitchens, home bars, offices, walk-in closets, and more.
| Overview | |
| Nominal Height | 34.0" (86 cm) |
| Height of Cabinet | 33.75" (86 cm) |
| Nominal Width | 6.0" (15 cm) |
| Width | 5.88" (15 cm) |
| Nominal Depth | 21.0" (53 cm) |
| Depth | 20.75" (53 cm) |
| Depth with Handle | 22.38" (57 cm) |
| Depth with door at 90° | 25.5" (65 cm) |
| Bottles | 7 bottles |
| Defrost Type | Automatic |
| Door | Glass/Panel-Ready Frame |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 40.0 lbs. (18 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101146782 |
| Wine Cellar | |
| Number of Zones | 1 |
| Door Swing | LHD |
| Height Adjustable | Yes |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.57 oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Interior Height 1 | 25.75" (65 cm) |
| Interior Width 1 | 3.5" (9 cm) |
| Interior Depth 1 | 14.25" (36 cm) |
| Compressor Step Width | 3.5" (9 cm) |
| Compressor Step Depth | 5.0" (13 cm) |
| Level Legs | 4 |
| Temperature Range | 41 to 72 F |
| Sabbath Mode | Yes |
| Sound Level | 33.8 dB |
