Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED AK1236CW

SKU/Model #: AK1236CW
Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED
Authorized Reseller
SKU/Model #: AK1236CW
Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED
Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED
Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED
Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED
Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED
Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED
Zephyr AK1236CW Breeze II, Under Cabinet, 36", White, LED
  • LumiLight LED Lighting
  • Electronic Touch Controls
  • Low-profile body
  • Extra-wide mesh filters
  • Vertical or horizontal ducting
  • Multiple color options
  • Optional Ductless Recirculating Kit
Breeze II, Under Cabinet, 36", White, LED
Brand Zephyr
Manufacturer Zephyr
Category Range Hood
Sub-Category Under Cabinet
Vent Type Convertible
UPC 646328009853
GTIN 00646328009853
Country of Origin Taiwan
Model Group AK12-C
Model Name Breeze II Under-Cabinet
Collection Core Collection
Blower Included Yes
Internal Blower 1 CFM 400
Internal Blower 1 Min. Sones 2
Internal Blower 1 Max Sones 5
Minimum CFM 210
Installation Type Under Cabinet
For Outdoor Use No
Color White
Controls Type Electronic
Blower Speeds 3
Automatic Delay-Off Yes
Clean Air Function No
Lighting Type LED
Lights Quantity 2
Watts Per Bulb 6
Lights Levels 2
Grease Filter Type Mesh
Compatible Mesh or Baffle Filter Part Number 50200012
Duct Discharge Vertical or Horizontal
Duct Size; Horizontal; IN 3.25 x 10
Duct Size; Vertical; IN 7, 3.25 x 10
Mounting Height Above Cooktop; IN 24 - 34
Voltage 120
Maximum Amperage 2
ADA Compliant No
Warranty Parts / Labor 3 / 1
Compatible Appliances ZRC-0012, 0AK11-20001, AK1716
Bluetooth Connected No
Wi-Fi Connected No
Remote Included No
Remote Optional No
Energy Star Certified No
Alexa & Google Home Compatible No
CEC Title 20 Compliant Yes
CEC Title 24 Compliant Yes
Primary Material Steel
Wattage 240
Certification UL
Nominal Width; IN 36
Net Width; IN 35.875
Net Depth; IN 20
Net Height; IN 5.5
Weight; LBS 24.3
Ceiling Height Minimum 8 ft.
Ceiling Height Maximum 12 ft.
Shipping Length; IN 39.3
Shipping Width; IN 9
Shipping Height; IN 24.25
Shipping Weight; LBS 34.5
Shipping Method Small Parcel
Freight Class 200
Certification # E127334
Clean Filter Alert Yes
Duct Type Vertical
Duct Type Vertical
