Amana AER6603SFW 30-inch Amana® Electric Range with Extra-Large Oven Window AER6603SFW
Amana AER6603SFW 30-inch Amana® Electric Range with Extra-Large Oven Window
- Bake Assist Temps use preset temperature settings for convenience
- Quickly select bake or broil temps with easy-to-read controls
- Keep an eye on your meal through the Extra-Large Oven Window
- Extra-Large Oven Window provides a bigger view to check on food
- 4.8 Cu. Ft. Capacity oven lets you cook multiple dishes at once
- Self-Clean Option does the dirty work for you in 2 to 4 hours
- Storage Drawer provides space to store pots and pans
- Temp Assure™ Cooking System distributes heat throughout the oven
- Versatile Cooktop has multiple element options up to 3,000 watts on the largest burner
- Warm Hold keeps the oven warm so dishes are ready when you are
This 30-inch Amana® Electric Range comes with a Versatile Cooktop featuring up to 3,000 watts, giving you more flexibility to turn up the heat! You can also set bake or broil temperatures with our Easy Touch Electronic Controls Plus. Or choose a preset temperature setting with Bake Assist Temps. And when you're finished cooking, use the Self-Clean Option to help clean up the buildup inside your oven.
| Certifications | |
| Ada Compliant | No |
| Prop65 | Standard |
| Ul | Yes |
| Controls | |
| Display Color | Green |
| Electronic Display Type | LED |
| Cooktop Details | |
| Cooktop Control Knob Color | Color Coordinated |
| Cooktop Control Knob Type | Dishwasher Safe Plastic |
| Cooktop Control Location | Backguard |
| Cooktop Control Type | Knobs |
| Cooktop Surface Color | Black |
| Cooktop Surface Material | Porcelain Coated Steel |
| Heating Element On Indicator Light | Yes |
| Hot Surface Indicator Light | Yes |
| Details | |
| Fuel Type | Electric |
| Lp Convertible | No |
| Oven Configuration | Single Oven |
| Oven Light Switch Location | Oven Control |
| Oven Selections | Audible Signal; Clock; Control Lock; Sabbath Mode; Timer; Warm Hold |
| Power On Indicator Light | Yes |
| Range Configuration | Freestanding |
| Range Drawer Type | Storage Drawer |
| Range Type | Freestanding |
| Dimensions | |
| Product Height | 46.875 |
| Carton Height | 48.75 |
| Gross Weight | 162 |
| Oven Interior Height | 18.125 |
| Carton Width | 32 |
| Product Depth | 27.75 |
| Oven Interior Depth | 18.5 |
| Depth With Door Open 90 Degree | 46.688 |
| Cutout Depth | 24 |
| Cutout Height | 36 |
| Depth Closed Excluding Handles | 25.313 |
| Carton Depth | 29 |
| Cutout Width | 30 |
| Oven Interior Width | 24.5 |
| Net Weight | 0 |
| Product Width | 29.875 |
| Electrical | |
| Power Cord Included | No |
| Element/burner Details | |
| Cooktop Element Style | Smoothtop |
| Left Front Element-burner Power | 3000W/1400W |
| Left Front Element-burner Size | 9in./6in. |
| Left Front Element-burner Type | Dual |
| Left Rear Element-burner Power | 1,200W |
| Left Rear Element-burner Size | 6in. |
| Left Rear Element-burner Type | Radiant |
| Number of Cooking Element-burners | 4 |
| Right Front Element-burner Power | 1200W |
| Right Front Element-burner Size | 6in. |
| Right Front Element-burner Type | Radiant |
| Right Rear Element-burner Power | 1,800W |
| Right Rear Element-burner Size | 8in. |
| Right Rear Element-burner Type | Radiant |
| Exterior Details | |
| Door Type | Glass Window |
| Handle Color | Stainless Steel |
| Handle Type | Towel Bar |
| Knob Color | White |
| Oven Control Knob Color | White |
| Oven Control Location | Backguard |
| Oven Control Type | Electronic Touch |
| Oven Window Size | Extra Large |
| Oven Details | |
| Bake Element Power | 2,400 W |
| Broiler Element Power | 3,400 W |
| Broiler Location | Top of Oven |
| Convection Element Type | None |
| Convection Functions | No |
| Door Removable | Yes |
| Hidden Bake Element | No |
| Interior Color | Grey |
| Natural Gas Convertible | No |
| Number of Oven Lights | 1 |
| Number of Oven Racks | 2 |
| Number of Rack Guides | 5 |
| Oven Cleaning Type | Adjustable Self Cleaning |
| Oven Cooking System | Thermal |
| Oven Light Type | Incandescent |
| Oven Rack Type | Standard |
