Elica ECL136S4 CALABRIA Undercabinet Range Hood 36" wide - 1200CFM ECL136S4

For homeowners who are passionate about the culinary arts, the seamless welded corner craftsmanship, traditional styling and gleaming stainless steel of Calabria, provides the look and performance expected from a professional-grade range hood. With the new backlit hidden knob controls and traditional ba_x001F_e filters, Calabria is available in 30 , 36 , 42 and 48 widths and equipped with a 600 CFM (30 and 36 ) or 1200 CFM blower (36 , 42 , 48 ) to support all cooking needs. Designed for standard ducted ventilation or recirculating with a kit.

Warranty	3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)	45.40
NET WEIGHT (kg)	39.40
CARTON LENGHT (mm)	1046.00
CARTON HEIGHT (mm)	625.00
CARTON WIDTH (mm)	764.00
VOLUMEN (M3)	0.50
SHIPPING WEIGHT	100.09
NET WEIGHT	86.86
CARTON LENGHT	41.18
CARTON HEIGHT	24.61
CARTON WIDTH	30.08
COUNTRY OF MANUFACTURE	MX
QTY PACKAGE	1.00
INTENDED APPROVED USE	Residential use
Finish	Stainless Steel
Color	inox
Type of Ventilation	Vented
HOODS FEATURES	Hush system,Heat guard,Grease collectors,Professional performance,Seamless look
WIDTH (IN)	36"
WIDTH (CM)	90.00
AIRFLOW (M3/H)	2040.00
CFM (MAX)	1200.00
db (min)	36.00
db (max)	56.00
SONES	1.7 - 8.5
EXHAUST VERSION	Convertible with Kit
EXHAUST SIZE	Round 8"
DUCT SHAPE	Round
EXHAUST LOCATION	Top Only
RECTANGULAR DUCTH HEIGHT	NA
RECTANGULAR DUCT WIDTH	NA
Round duct diameter	8"
ELECTRIC (VOLTS)	120 V/60 Hz
AMPERAGE	7,6 A
HERTZ	60.00
WATTS	913.00
LIGHTING	Premium LED 2 x 6.5 ww 3000 KK
BULB TYPE	LED
BULB INCLUDED	YES
NUMBER OF LIGHTS	2.00
BULB WATTS	6.50
KELVINS	3000.00
GREASE FILTER TYPE	Dishwasher-Safe, Professional Stainless Steel Angled Baffle Filter
DISHWASHERSAFE FILTER	YES
FILTER MATERIAL	Stainless Steel
BLOWER TYPE	Interior Unit
CONTROL TYPE	Fully Retractable Rotating Knobs w/ Blue Backlighting
SPEED CONTROL	YES
NUMBER OF SPEEDS	4.00
REMOTE CONTROL	NO
POWER SOURCE	Hardwired
OUTDOOR USE	NO
SMUDGE RESISTANT	NO
RECIRCULATION KIT NEEDED	NO
CFM REDUCTION	Yes w/kit
DIMENSIONS	91 x 64 x 46
DIMENSIONSinches	36" x 25" x 18"
ADJUSTABLE HEIGHT	NO
Minimum Overall Height - Top to Bottom	18"
Maximum Overall Height - Top to Bottom	22 5/16
Overall Height - Top to Bottom	18"
Overall Width - Side to Side2	36"
Overall Depth - Front to Back	25"
Hood Height	18"
Minimum Compatible Ceiling Height	NA
Maximum Compatible Ceiling Height	NA
Minimum Height Above Cooktop (ELECTRIC)	= 24
Minimum Height Above Cooktop (GAS)	= 30
Maximum Height Above Cooktop	36"
Chimney Width - Side to Side	NA
Chimney Depth - Front to Back	NA
Chimney Height - Top to Bottom	NA
RECIRCULATION KIT NUMBER	KIT0192765 + KIT0192763+KIT0204547
CHIMNEY EXTENSION NUMBER	KIT02158/KIT02161
TELESCOPIC DUCT COVER	-
DUCT TRANSITION	-
TRANSITION REDUCER KIT	-
BACKDRAFT DAMPER	-
NON RETURN VALVE	-
UPGRADE FILTER	-
CFM REDUCTION KIT	KIT0185099
BACKSPLASH KIT	KIT0142867
INTERNAL BLOWER	-
INLINE BLOWER	-
EXTERNAL BLOWER	-
INLINE BLOWER SHELL KIT	KIT0179549
EXTERNAL BLOWER SHELL KIT	KIT0179547
HEAT LAMPS	KIT0155107
SPACER/LINER	-
WALL MOUNT BRACKET	-
HIGH CEILING EXTENSION KIT	-
REMOTE CONTROL KIT	-
cUL listed	YES
UL listed	YES
AHAM verified	YES
TITLE 24	YES
Prop65Disclosure	YES
ENERGY STAR	NO
WIFI CAPABLE	NO
COMERCIAL USE APPROVED	NO
ADA COMPLIANT	NO
APP CAPABLE	NO
VENTILATION DIRECTION	HORIZONTAL
SMART COMPATIBLE	NO
FITLER INDICATOR LIGHT	NO
HEAT SENSOR	YES
CHAROCAL FILTER	NO
CERTIFICADO NOM	NA
