LG 22KC3PM
Authorized Reseller
Lg 22KC3PM 22'' FHD In-Cell Touch Self-Service Kiosk with Customizable Peripherals & USB Type-C ports
Lg 22KC3PM 22'' FHD In-Cell Touch Self-Service Kiosk with Customizable Peripherals & USB Type-C ports
Item Not Available
Couldn't load pickup availability
Check Delivery:
- Modular design allows for easy integration of devices like barcode scanners
- Landscape & portrait display orientation
- Versatile stand options for a variety of installation needs (Stands sold separately)
- Accessible core hardware components for optimized serviceability
- Compatible with extensive POS systems & apps with Windows OS
22'' FHD In-Cell Touch Self-Service Kiosk with Customizable Peripherals & USB Type-C ports
| System | |
| Operating System (OS) | Windows 10 IOT Enterprise (Basic) |
| Storage | SSD 128 GB |
| Internal Memory | 8 GB RAM |
| Electrical | |
| Power Type | Built-in Power |
| Power Consumption (Max.) | 87 W |
| Power Supply | 100~240V (50/60 Hz) |
| Power Consumption | 42 W |
| Connectivity | |
| HDMI In | No |
| IR In | No |
| DVI-D In | No |
| RGB In | No |
| Audio In (3.5 mm) | No |
| DisplayPort In | No |
| RJ11 | No |
| RJ45 (LAN) In | Yes (x1) |
| USB Type-A In | Yes (x4) USB 3.0 (x2), USB 2.0 (x2) |
| USB Type-C In | Yes (x4) USB 2.0 |
| Power In (DC From External PWR Box) | Yes (x1) |
| Power Loop In | No |
| HDMI Out | No |
| DisplayPort Out | No |
| Audio Out (3.5 mm) | No |
| Touch USB | No |
| IR Out | No |
| RJ45 (LAN) Out | No |
| RS-232C Out | No |
| External Speaker Out | No |
| Power Loop Out | No |
| Daisy Chain | No |
| Panel | |
| Screen Size (Inches) | 21.5" |
| Panel Technology | VA |
| Backlight Type | Edge |
| Aspect Ratio | 16:9 |
| Resolution | 1920 x 1080 (FHD) |
| Refresh Rate | 60 Hz |
| Brightness (Typ.) | 250 nits |
| Contrast Ratio | 3000:1 |
| Dynamic Contrast Ratio | No |
| Color Gamut | NTSC 50%, sRGB 72% |
| Color Depth (Number of Colors) | 8 bit |
| Viewing Angle (H x V) | 178° x 178° |
| Response Time (G to G) | 8 ms |
| Surface Treatment (Haze) | 3% |
| Operation Hours (Hours/Day) | 16/7 |
| Lifetime | Up to 31,000 Hrs |
| Orientation | Portrait / Landscape |
| Transparency | No |
| QWP (Quarter Wave Plate) | Yes |
| Audio/Sound | |
| Built-in Speakers | Yes (x2) 2W |
| Mechanical | |
| Color | Titan |
| Weight | 10.58 lbs / 4.8 kg |
| Shipping Weight | 10.58 lbs / 7.23 kg |
| Desktop Dimensions (W x H x D) | 20.42 x 11.82 x 1.77 in / 518.7 x 300.3 x 45 mm |
| Desktop Dimensions with Cradle (W x H x D) | No |
| Shipping Dimensions (W x H x D) | 23.46 x 14.88 x 5.90 in / 596 x 378 x 150 mm |
| Conformal Coating (Power Board) | No |
| VESA™ Standard Mount Interface | 100 x 100 mm |
| Overlay Touch Compatibility | No |
| Smart Calibration | No |
| Power Protection | No |
| Direct Sunlight | No |
| LG Software Compatible | |
| SuperSign™ Control+ | No |
| SuperSign™ WB | No |
| SuperSign™ CMS | No |
| SuperSign™ Cloud | No |
| Mobile CMS | No |
| ConnectedCare™ | Yes |
| Regulatory & Certifications | |
| UL Certification | Yes |
| ISTA6 (Packaging) | No |
| ERP (Environmental) | Yes |
| FCC (Regulatory) | Yes |
| IP Rating (Solid / Liquid Ingress) | No |
| Energy Star (Environmental) | Yes |
| TAA Compliance | No |
| Warranty & Other | |
| Warranty | 3 Year Limited |
| Assembled In | China |
| UPC | 195174131305 |
| Optional Accessories | Countertop Stand (ACC-ST-KC3P) Floor Stand (ACC-SF-KC3P) Back-to-back Stand (ACC-SB-KC3P) Universal Stand (ACC-SU-KC3P) Barcode / QR Scanner (ACC-PS-KC3P) 6-key Tactile Keypad (ACC-PK-KC3P) 9-key Tactile Keypad (ACC-PE-KC3P) |
| Basic Accessories (included) | Adapter, Power Cable(1.8m), Cradle for Payment Terminal, Screws, Manual, Cap rubbern |
| Hardware Features | |
| NFC / RFID | No / No |
| Audio Navigation Keypad | Yes |
| Cable Management | No |
| QR / Barcode Scanner | 1D / 2D |
| Cradle for External Card Reader | Yes |
| Body / Stand Type | Optional - Floor Stand (ACC-SK-KC3P) |
| Receipt Printer | |
| Paper Size | Compatible with Epson TM-TM88Vll, TM-m30lll, TM-L100 |
| Printing Speed | Compatible with Epson TM-TM88Vll, TM-m30lll, TM-L100 |
| Type | Compatible with Epson TM-TM88Vll, TM-m30lll, TM-L100 |
| Cutting | Compatible with Epson TM-TM88Vll, TM-m30lll, TM-L100 |
| Front Drawer | |
| Type | N/A |
| Area | N/A |
| Accessibility | |
| Braille Assistive Guide | No |
| Audio Assistive Technology | EN 301 549 / ADA Compliant, Mini USB B & 3.5 mm Audio Jack Socket, Storm interface AudioNav Keypad |
| Environmental Conditions | |
| Operation Humidity | 10% to 80% |
| Operation Temperature | 32°F to 104°F / 0°C to 40°C |
| OPS Compatibility | |
| OPS Compatible | No |
| OPS Power Built-in | No |
