LG 27KC3PKC
Authorized Reseller
Lg 27KC3PKC 27" FHD In-Cell Touch Self-Ordering Kiosk with QSR/Barcode Scanner, Card Reader, & Thermal Receipt Printer
Lg 27KC3PKC 27" FHD In-Cell Touch Self-Ordering Kiosk with QSR/Barcode Scanner, Card Reader, & Thermal Receipt Printer
Item Not Available
Couldn't load pickup availability
Check Delivery:
- 27" FHD (1,920 x 1,080) In-Cell Touch Displayt
- Windows® 10 IoT Enterprise & Intel® Celeron® Quad-Core N5105 SoC Onboard Processorst
- QSR/Barcode Scanner, Card Reader, &Thermal Receipt Printert
- Audio Assistive Technology & Braille Assistive Guidet
- Built-in Speakerst
27" FHD In-Cell Touch Self-Ordering Kiosk with QSR/Barcode Scanner, Card Reader, & Thermal Receipt Printer
| System | |
| Operating System (OS) | Windows® 10 IoT Enterprise (Compatible with Windows® 11) |
| Processor | Intel® Celeron® Quad-Core N5105 SoC onboard Processors (Jasper Lake) |
| Storage | SSD 128 GB |
| Internal Memory | 2 x SO-DIMM, 8 GB (Max 16 GB), DDR4 2933 / 2400 / 2133 MHz |
| Electrical | |
| Power Type | Built-in Power |
| Power Consumption (Sleep Mode) | 0.5W |
| Power Consumption (On Mode) | 40W |
| Related Voltage | 220 Vac, 60 Hz |
| Connectivity | |
| HDMI In | No |
| IR In | No |
| DVI-D In | No |
| RGB In | Yes (x1) |
| Audio In (3.5 mm) | Yes (x1) |
| DisplayPort In | No |
| RJ11 | Yes (x1) (For Cash drawer 12V/24V) |
| RS-232C In | (1x) RS232 / 422 / 485, (2x) RS232 5 / 12 / Ring switch by BIOS, Yes (x3) |
| RJ45 (LAN) In | Yes (x1) |
| USB Type-A In | Yes (x4) USB 3.2 |
| Power In (DC From External PWR Box) | Yes (x1) DC-12V, 4-pin Lockable DC Jack 4P Connector |
| Power Loop In | No |
| HDMI Out | Yes |
| DisplayPort Out | No |
| Audio Out (3.5 mm) | Yes (x1) |
| Touch USB | No |
| IR Out | No |
| RJ45 (LAN) Out | No |
| RS-232C Out | No |
| External Speaker Out | No |
| Power Loop Out | No |
| Daisy Chain | No |
| Panel | |
| Screen Size (Inches) | 27" |
| Panel Technology | IPS (in-cell touch) |
| Backlight Type | Edge |
| Aspect Ratio | 16:9 |
| Resolution | 1920 x 1080 (FHD) |
| Refresh Rate | 60 Hz |
| Brightness (Typ.) | 300 nits |
| Contrast Ratio | 1000:1 |
| Dynamic Contrast Ratio | No |
| Color Gamut | BT709 95% |
| Color Depth (Number of Colors) | 16.7 Million Colors, 8 bit |
| Viewing Angle (H x V) | 178° x 178° |
| Response Time (G to G) | 9 ms |
| Surface Treatment (Haze) | Haze 25% |
| Operation Hours (Hours/Day) | 16/7 |
| Lifetime | Up to 31,000 Hrs |
| Orientation | Portrait / Landscape |
| Transparency | No |
| QWP (Quarter Wave Plate) | No |
| Audio/Sound | |
| Built-in Speakers | Yes (x2) 3W Stereo Max |
| Mechanical | |
| Color | Beige (Desktop) |
| Tilt (Face Down) | No |
| Tilt (Face Up) | No |
| Weight | 32.2 lbs / 14.6 kg |
| Desktop Dimensions (W x H x D) | 14.3 x 32.0 x 8.7 in / 364.3 x 812 x 219.8 mm |
| Desktop Dimensions with Cradle (W x H x D) | 14.3 x 32.0 x 13.5 in / 364 x 812 x 342 mm |
| Conformal Coating (Power Board) | No |
| VESA™ Standard Mount Interface | 600 x 400 mm |
| Overlay Touch Compatibility | No |
| Smart Calibration | No |
| Power Protection | No |
| Direct Sunlight | No |
| LG Software Compatible | |
| SuperSign™ Control+ | No |
| SuperSign™ WB | No |
| SuperSign™ CMS | No |
| SuperSign™ Cloud | No |
| Mobile CMS | No |
| ConnectedCare™ | No |
| Regulatory & Certifications | |
| UL Certification | No |
| ISTA6 (Packaging) | No |
| CE (Regulatory) | No |
| ERP (Environmental) | No |
| U.S. ePEAT (Environmental) | No |
| FCC (Regulatory) | No |
| IP Rating (Solid / Liquid Ingress) | No |
| Energy Star (Environmental) | No |
| TAA Compliance | No |
| Warranty & Other | |
| Warranty | 3 Year Limited |
| Assembled In | South Korea |
| UPC | 1 95174 05505 2 |
| Optional Accessories | NICE TCM stand |
| Hardware Features | |
| NFC / RFID | No / No |
| Audio Navigation Keypad | Yes |
| Cable Management | Yes |
| QR / Barcode Scanner | 1D / 2D |
| Cradle for External Card Reader | Yes |
| Body / Stand Type | Mold (Main Body), Press (Stand, optional) |
| Card Reader | It depends on payment terminal |
| Receipt Printer | |
| Paper Size | 3 in (Roll diameter 80 mml) |
| Printing Speed | Max 250 mm/sec |
| Type | Thermal |
| Cutting | Auto |
| Front Drawer | |
| Type | Sliding |
| Area | Bar code scanner, Card reader, Receipt printer |
| Accessibility | |
| Braille Assistive Guide | Yes (Embossed Braille with Arabic numerals) |
| Audio Assistive Technology | EN 301 549 / ADA Compliant, Mini USB B & 3.5 mm Audio Jack Socket, Storm interface AudioNav Keypad |
| Environmental Conditions | |
| Operation Humidity | 10% to 80% |
| Operation Temperature | 32°F to 104°F / 0°C to 40°C |
| OPS Compatibility | |
| OPS Compatible | No |
| OPS Power Built-in | No |
