Lg CVBA CVBA LED Controller
Lg CVBA CVBA LED Controller
Item Not Available
Couldn't load pickup availability
Check Delivery:
- Compatible with LSBB, LSBC, LSBE, LSBF, LHBB, LWBC, & GMBD Series LED signage
- webOS 4.0
- Easily manage with LG ConnectedCare & SuperSign CMS
CVBA LED Controller
| Unit Case | |
| LED Compatibility | GMBD, LHBB, LSBB, LSBC, LSBE, LSBF, LWBC |
| System | |
| Operating System (OS) | webOS 4.0 w/Open API Support |
| System Memory | 8 GB (System 4 GB + Available 3.6 GB) |
| Input | |
| HDMI | Yes (x1) HDMI 2.0 |
| DisplayPort | Yes (x1) DP 1.2 / HDCP 1.3 |
| HDCP | HDCP 2.2 |
| USB Type-A | Yes (x1) USB 2.0 |
| Output | |
| Ethernet | Yes (Gigabit Ethernet X 16) |
| Control | |
| USB | Yes (x1) |
| GenLock | No |
| RS-232C In/Out (4 Pin phone-jack) | Yes |
| Electrical | |
| Power Supply | AC 100-240V~, 50/60 Hz |
| Power Type | Built-in Power |
| Power Consumption | 50W |
| Connectivity | |
| Bluetooth | Yes |
| Built-in Wi-Fi | Yes |
| Mechanical | |
| Weight | 10.9 lbs / 4.9 kg |
| Dimensions (W x H x D) | 17.4 x 12.1 x 2.5 in / 443 x 307.5 x 64 mm |
| LG Software Compatible | |
| LED Assist | Yes |
| SuperSign™ CMS | Yes |
| ConnectedCare™ | Yes |
| Regulatory & Certifications | |
| KC | Yes |
| CB | Yes |
| NRTL | Yes |
| FCC (Regulatory) | EMC Class A |
| CE (Regulatory) | Yes |
| TAA Compliance | Yes |
| Warranty & Other | |
| Warranty | 3 Year Limited |
| Assembled In | Slovakia |
| UPC | 195174073315 |
| Max Output Range | |
| Output Resolution | 8.2944 Million Pixels |
| Loading Capacity | 3,840 x 2,160 @ 60Hz |
| Hardware Features | |
| Temperature Sensor | Yes |
| Local Key Operation | Yes |
| Signal Redundancy | Yes |
| Sensors | |
| Temperature | Yes |
| Video Processing | |
| resolution | 3,840 x 2,160 @ 60 Hz |
| Chroma Adjustment | Yes |
| Brightness Adjustment | Yes |
| Scaling | Yes |
| Format | RGB YCbCR4:4:4 YCbCr4:2:2 |
| Improved Grayscale at Low Brightness | Yes |
| HDR10 Pro | Yes |
| Environmental Conditions | |
| Operation Temperature | 32°F to 104°F / 0°C to 40°C |
| Operation Humidity | 10-80% RH |
