LG LAAB136BXNA
Authorized Reseller
Lg LAAB136BXNA 136" LAAB All-in-One Micro LED Display
Lg LAAB136BXNA 136" LAAB All-in-One Micro LED Display
Item Not Available
Couldn't load pickup availability
Check Delivery:
- All-in-One screen with built-in speakers
- Deep blacks, 40,000:1 contrast
- Easy installation in four steps*
- Uniform, high-fidelity color
136" LAAB All-in-One Micro LED Display
| Physical Parameters | |
| LED Type | Micro |
| Pixel Pitch | 0.03 in / 0.78 mm |
| Screen Size (Inches) | 136" |
| Screen Resolution (W x H) | 3,840 x 2,160 (UHD) |
| Module Resolution (W x H) | 384 x 144 |
| Module Dimensions (W x H) | 11.81 x 4.42 in / 300 x 112.5 mm |
| No. of Modules per Screen (W x H) | 10 x 15 (Total 150) |
| Screen Dimensions (W x H x D) | 118.30 x 66.63 x 1.55 in / 3,005 x 1,692.5 x 39.4 mm |
| Screen Surface Area | 54.46 ft / 5.06 |
| Weight | 334.00 lbs / 151.5 kg |
| Physical Pixel Density | 1,638,400 pixels/m |
| Flatness of Cabinet | 0.2 mm |
| Cabinet Material | Aluminum |
| Service Access | Front |
| Electrical | |
| Power Consumption (Max.) | 1,500W |
| Heat Dissipation (Max.) | 5,118 BTU |
| Power Supply | 100-240V |
| Refresh Rate | 3,840 Hz |
| Heat Dissipation (Avg.) | 3,071 BTU |
| Power Consumption (Avg.) | 900 nits |
| Power Consumption per Unit Area (Max.) | 296 nits |
| Heat Dissipation per Unit Area (Max.) | 1,011 BTU/h/ |
| Connectivity | |
| HDMI In | Yes (x3) HDCP 2.2 |
| DisplayPort In | Yes (x1) |
| RS-232C In (3.5 mm 4-pin) | Yes (x1) |
| RJ45 (LAN) | Yes (x1) |
| Optical Digital Audio Out | Yes (x1) |
| Built-in Wi-Fi | Yes |
| Controller | |
| Controller | Embedded webOS 8.0 |
| Optical | |
| Max. Brightness (After Calibration) | Up to 1,600 nits |
| Color Temperature | 3,200-9,300K |
| Viewing Angle (H x V) | 160° x 160° |
| Brightness Uniformity | 95% |
| Color Uniformity | 0.015 Cx, Cy |
| Contrast Ratio | 40,000:1 |
| Processing Depth | 20 bit (HDR10, HDR10 Pro) |
| Lifetime | 150,000 Hrs |
| Audio/Sound | |
| Built-in Speakers | Yes (x2) 10W |
| Features | |
| Magic Remote Compatibility | Yes |
| Crestron Certified Compatibility | Yes |
| Regulatory & Certifications | |
| IP Rating (Rear) | IP20 |
| RoHS (Environmental) | Yes |
| IP Rating (Front) | IP50 |
| FCC (Regulatory) | EMC Class B |
| BS476 Part7 (UK Fire Rating) | Yes |
| Safety 60950-1 | Yes |
| TAA Compliance | No |
| Warranty & Other | |
| Warranty | 3 Year Limited |
| Assembled In | Korea |
| UPC | 195174149508 |
| Basic Accessories (included) | IR Remote(In-box), Magic Remote (In-box), Side by Side : Yes (1xN)n |
| Environmental Conditions | |
| Operation Temperature | 32°F to 104°F / 0°C to 40°C |
| Operation Humidity | 10-80% RH |
